Multi - Flute, Corner Radius - Knuckle Rougher, Variable Pitch, Reduced Neck (Aplus)

The staggered “low profile” edge geometry of the HXVR-RN makes it easy to hog out steels and other tough materials. Its Aplus coating offers increased lubricity, and the reduced neck offers optimal strength for machining within deep cavities.

• Offers outstanding performance and high temperature resistance in a wide range of ferrous materials, including low and medium alloy steels, tool steels, and cast iron
• Engineered with staggered "low profile" edge geometry for chip control and minimized cutting forces
• Available in 4 flute and 5 flute options
• Reduced neck provides maximum strength in long reach and deep pocketing applications
• Center cutting
• h6 shank tolerance for high precision tool holders
• Aplus coating offers added lubricity and high temperature resistance for faster speeds and feeds and improved tool life
• Solid carbide end mills
• CNC ground in the USA

Slotting

Plunging

3D Contouring

Roughing
